PLS-6030 30W C02 Laser System
Small Footprint, Big Results
The Prytec PLS-4030 Advanced Laser System is designed for businesses in need of a Laser machine with a small footprint. Using a 30W Metal CO2 Laser source, the PLS-4030 is compact but still packs a punch. The metal tube also eliminates the need for water cooling which again cuts back the footprint in your workshop or office.
Expand your business by adding versatility and personalisation to your products.
Prytec Laser Systems are designed to cut and etch all sorts of materials including acrylics with ease, leaving you a beautiful polished finished edge, it will also etch text and graphics in high detail. The 400x300mm working area is ideal for small to medium engraving and cutting jobs. The convenient desktop size allows for a small footprint in your workshop.
Easy to Use
The PLS Laser System has been developed with keeping ease of use in mind. Plugged in via USB cable or connected via Wifi, the unit has a touch screen controller on the machine to move the machine to the location required (if working with an offcut), or to change settings 'on-the-fly', without going back to the pc.
The automated air assist automatically opens and closes the air valve so you do not have to flick a switch.
Materials
The Prytec Laser Systems can handle a wide variety of materials. You can Engrave onto acrylic, anodised aluminum, metals*, wood, leather, paper, fabric and more. You can also cut materials like Acrylic, fabric, leather, stamp material, timber etc. The effects and creations are up to your imagination.
* A marking spray must be used to mark bare metals with a CO2 laser.
Our 30w Metal Laser Tube has a 6,000+ hour life span.
Enquire Download BrochureSpecifications:
| External dimensions | 760 mm W x 1070 mm D x 900 mm H (or 650mm with No Base) |
| Laser source | 30W CO2 RF Laser Tube |
| Max Engrave Speed | 600mm/sec |
| Max Cut Speed | 70mm/sec |
| Work Area | 600 x 300mm |
| Max Engrave Area | 550 x 300mm |
| Location Precision | Less than 0.01mm |
| Scanning Precision | up to 1000 dpi |
| Minimum Character Size | 1.0 mm x 1.0mm |
| Rapid Speed | 140,000 mm/min |
| Motors | Hybrid Stepper Motors |
| Graphic File Types | PDF, PNG, HPGL, PLT, BMP, DXE, DXF, AI |
| Warranty | 2 years (including Laser Source) |
All Prytec Laser Systems come with LightBurn software specifically designed and created for Laser Systems.
EngraveLAB V10 Ruida Edition
Bundled with CADLinks EngraveLAB Ruida Edition software facilitates the production of a wide variety of jobs, from simple nameplates to elegant wood signs and luxury stationary. EngraveLAB Ruida Edition generates quality results with photos Bitmaps and Vector Art Work. The software imports designs in AI, EPS, PDF, DXF, BMP, JPG file formats. It also allows users to design and modify files to suit.
The motorized height adjustable table increases the variety of objects you will be able to engrave and cut.
Prytec PLS-4030 is supplied with all ancillary equipment needed including
- Exhaust Fan.
- Air assist Compressor.
- 2m of 100mm flexible ducting for exhaust.
